Ezi Security’s APT50A High Security Rising Bollard provides maximum protection against hostile vehicle attacks. It has been tested using
an empty 18-ton European lorry, offering superior protection compared to bollards certified only
with the smaller N2 vehicle. It was fully tested at TRL with an N3 7.5-ton vehicle at 80 kph. Like all
Eagle Automation bollards, the APT50A was tested as a single unit with a single foundation and is
supplied complete with integral re-bar for fast installation.
Features• Manufactured by Eagle Automation in the UK
• Impact tested as a single unit in a single foundation
• Supplied with integral re-bar for simple installation
• 323 mm diameter bollard (painted finish)
• 1200 mm raised height above ground
• Available in painted, stainless steel, or bespoke finishes
• Custom stainless steel sleeve options
• Operates after impact, withstands multiple attacks
• 3-phase power at 10 amp
• 100% duty cycle
• Raise/lower time: 8–10 seconds
• Optional emergency fast operation
• Optional LPS SR2 or LPS SR4 security cabinets
• Complies with all safety standards
• Supplied with high-performance control board
• Can operate standalone, with other products, or as a tiger trap
• Manual option available via drill or hand pump
• Certification: V7500(N3)80/90:5.9
The APT50A is the ultimate solution for facilities requiring the highest level of vehicle attack protection.
